- Supply voltage : 230 VAC, 50/60 Hz (L & N)(No auxiliary supply)
- Output Contacts : Two SPDT (C-N/O-N/C) Relay, Rating5A at 250V AC
- Indications : FAULT (UB/SPP/REVP, UV, OV): RED LED, Mains RELAY ON, DG Relay ON: GREEN LED
- Keys : GREEN LED
- Keys:
1) SET : SET key, Press to enter into SET Mode
2) INC : Upward Arrow key, Press to increment the set point.
3) DEC : Downward Arrow key, To Decrement the set point.
- Mounting : Door Mounting.
- Dimensions : 96(L) * 96(W) * 110(D), mm.
- Microcontroller based technology.
- Protection against under voltage, Over voltage, All the set points settable by keys.
- Trip Delay is settable
- Reverse Phasing Protection can be bypass through Settings.
- Indications for Under Voltage, Over Voltage, Mains ON & DG Supply Available.
- If mains supply is absent works on DG supply.
